Senior PURe SLIDE Door

<img class="alignnone size-full wp-image-1798" src="https://mlzyzcsnmlqg.i.optimole.com/w:auto/h:auto/q:mauto/f:best/https://eximiaglazing.co.uk/wp-content/uploads/2023/11/product-senior-pure-slide-door-01.jpg" alt="Senior PURe SLIDE Door” width=”1200″ height=”531″ />

The PURe® SLIDE high performance aluminium door range features our innovative patented expanded polyurethane (PUR) thermal barrier, allowing ultra-low U values to be achieved.

Both inline slide and lift & slide configurations are also available as a slimline version (PURe® SLIDE SL) with a 50mm interlock sightline for uninterrupted views, whilst the heavy-duty Lift & Slide option allows leaf weights up to 300Kg.

All doors are available pre-finished in an almost unlimited range of colours and finishes both inside and out, in heights up to 3m and are easy to fabricate, install and adjust.

Construction

  • Unique jointing method of head and sill allows thermal breaks to always line through with door sash for thermal efficiency
  • Adjustable locking points for easy locking and weatherproof seal
  • Choice of chamfered or square beads, or Mix and Match
  • All hardware is securely fixed into the aluminium profiles, not the thermal break, to avoid thermal bridging and provide a more secure fixing
  • Simple drainage option allows cill to be dropped down to give a lower threshold for easy access
  • Backer rod and EPS insert available for improved thermal performance
  • High tech roller design for years of trouble-free operation

Fabrication and Installation

  • Same sight lines and sections for inline sliding and standard duty lift & slide doors
  • Constructed using mitred corners with alignment chevrons to assist in clean, accurate mitres
  • No need for complicated drainage preps to outerframe track
  • Mechanical corner cleats for ease of fabrication
  • Punch tool available for help in fabrication
  • Adjustable locking points and rollers for quick and easy installation
  • Delivery in 3 working days for stocked single colour profiles (anthracite grey and hipca white)
Brochure

* Sections provided are typical examples of this window system, there are many options available, for details of the exact sections used in your quote, please request the CAD detail from us when discussing your quote.

Properties

CEN standard (Double Glazed)
1.4 W/m²K
CEN standard (Triple Glazed)
0.95 W/m²K
Glazing thickness
28mm – 52mm
Max Door Leaf Width
3005mm
Max Door Leaf Height
2916mm
Max Outerframe Height
3000mm
Max Weight Per Door Leaf (Inline Standard Duty)
160Kg
Max Weight Per Door Leaf (Lift & Slide Standard Duty)
200Kg
Max Weight Per Door Leaf (Lift & Slide Heavy Duty)
300Kg

Performance

Reynaers CS77 Windows and Doors
Security
PAS24 & SBD

The technical information shown above is based on typical tests, the size of the windows, glass choice and profile choice can all affect the achieved rating, please ask us if you are unsure what your actual windows achieve, we are able to provide a variety of reports.
