Senior PURe SLIDE Door

The PURe^® SLIDE high performance aluminium door range features our innovative patented expanded polyurethane (PUR) thermal barrier, allowing ultra-low U values to be achieved.

Both inline slide and lift & slide configurations are also available as a slimline version (PURe^® SLIDE SL) with a 50mm interlock sightline for uninterrupted views, whilst the heavy-duty Lift & Slide option allows leaf weights up to 300Kg.

All doors are available pre-finished in an almost unlimited range of colours and finishes both inside and out, in heights up to 3m and are easy to fabricate, install and adjust.

Features
Downloads
Technical Information
Opening Options

Construction

Unique jointing method of head and sill allows thermal breaks to always line through with door sash for thermal efficiency
Adjustable locking points for easy locking and weatherproof seal
Choice of chamfered or square beads, or Mix and Match
All hardware is securely fixed into the aluminium profiles, not the thermal break, to avoid thermal bridging and provide a more secure fixing
Simple drainage option allows cill to be dropped down to give a lower threshold for easy access
Backer rod and EPS insert available for improved thermal performance
High tech roller design for years of trouble-free operation

Fabrication and Installation

Same sight lines and sections for inline sliding and standard duty lift & slide doors
Constructed using mitred corners with alignment chevrons to assist in clean, accurate mitres
No need for complicated drainage preps to outerframe track
Mechanical corner cleats for ease of fabrication
Punch tool available for help in fabrication
Adjustable locking points and rollers for quick and easy installation
Delivery in 3 working days for stocked single colour profiles (anthracite grey and hipca white)

* Sections provided are typical examples of this window system, there are many options available, for details of the exact sections used in your quote, please request the CAD detail from us when discussing your quote.

Properties

Performance

The technical information shown above is based on typical tests, the size of the windows, glass choice and profile choice can all affect the achieved rating, please ask us if you are unsure what your actual windows achieve, we are able to provide a variety of reports.
