ALuK SL52 Curtain Walling System

The SL52 Curtain Walling System is a flexible capped solution designed to offer high performance. Our aluminium curtain walls enable specifiers to create impressive facades that not only enhance the aesthetics of a building but also provide the functionality and performance required to meet and exceed current standards.

Features
Downloads
Technical Information
Opening Options

Design features

52mm capped high rise curtain walling system
Glass loads of up to 400kg
Can be faceted, curved or angled
Various drainage methods including mullion and zonal
Large range of box sizes to optimise small to large spans of glazing
CWCT Certified
Fully integrates with all AluK window and door ranges

Options

Glazing and infill range from 6mm – 50mm
Fully integrated vent options including POV, TBT, Top Hung, Side Hung, Fixed Light
Wide range of face cap options to meet design requirements
Available in single or dual colour option, polyester powder coating and anodised finishes

* Sections provided are typical examples of this window system, there are many options available, for details of the exact sections used in your quote, please request the CAD detail from us when discussing your quote.

Properties

Performance

The technical information shown above is based on typical tests, the size of the windows, glass choice and profile choice can all affect the achieved rating, please ask us if you are unsure what your actual windows achieve, we are able to provide a variety of reports.
