ALuK Optio BSC94 inline sliding door

Modern, versatile, premium.

Combining high performance with stunning design, our sliding aluminium door systems provide a versatile solution for any architectural project. Manufactured to the highest UK standards, this multi-configuration inline system offers outstanding thermal performance and a wide range of customisable options.

Features
Downloads
Technical Information
Opening Options

Design features

Accepts 20 – 31mm double glazing
Max 400kg panel weight
Certified PAS 24
Anti bi-metal polyamide strip to allow for varying expansion rates

Options

Accepts 20 – 31mm double glazing
Max 400kg panel weight
Certified PAS 24
Anti bi-metal polyamide strip to allow for varying expansion rates

* Sections provided are typical examples of this window system, there are many options available, for details of the exact sections used in your quote, please request the CAD detail from us when discussing your quote.

Properties

U value W/m²K (Double glazing) (Mono rail)

1.7 W/m²K

U value W/m²K (Triple glazing) (Mono rail)

1.5 W/m²K

U value W/m²K (Double glazing) (Duo rail)

1.9 W/m²K

U value W/m²K (Triple glazing) (Duo rail)

1.7 W/m²K

Certifications

C Rated

Max Vent Weight

400 kg

Max Frame Height

3000 mm

Max Frame Height with security features

2600 mm

Sightline (Head)

115.5 mm

Sightline (Cill)

115.5 mm

Sightline (Jamb)

115.5 mm

Max sash width (mm)

2000 mm

Sightlines

85 mm

Dual colour option

Yes

Multi-point locking

Yes

Glazing options

Internal

Glazing thickness

20mm – 31mm

Performance

Comfort

Safety

Energy

The technical information shown above is based on typical tests, the size of the windows, glass choice and profile choice can all affect the achieved rating, please ask us if you are unsure what your actual windows achieve, we are able to provide a variety of reports.
